Fire curtains

Why choose fire curtains?

DAN-doors' fire curtains range from a certification of 30 minutes to a classification of up to 240 minutes. The fire curtains are certified in EI, EW or E-class respectively.

EI-CLASS FIRE Curtains highest fire safety for all purposes

WithEI-class fire curtains, you get a solution that meets the strictestsafety requirements. EI curtains consist of 3 or 5 layers of reinforced glass fiber with insulating material and provide the highestlevel of protection against the spread of fire and smoke. EI curtains effectively reduce heat on the opposite side and can therefore be used in connection withevacuation routesand to protect against damage caused by heat and smoke.

The curtains are prepared for external ABA/ABDL signals so that it automatically runs down in case of fire.

The fire curtain has a discreet design and the guide rails are normally available in steel or in RAL colours 7035, 9002 or 9010. They can optionally be supplied painted in custom RAL colours to integrate the system into the overall design of the environment in which it is installed.

FIRE Curtains EW-CLASSEN high fire safety in a lightweight construction

EW class fire curtains rank among the safest on the market and are used to prevent the spread of fire between buildings, floor sections and fire zones. The curtains are made of 2-layer reinforced glass fabric and are laminated with aluminium foil, which provides heat reduction on the opposite side and protection against radiant heat.

The fire curtains are prepared for external ABA/ABDL signals, so that it automatically runs down in case of fire.

The system is available both wall-mounted and niche-mounted and has a lightweight construction that makes it easy to install. The curtains require a minimum of space and can be installed in locations with very low installation heights, making it suitable for locations where height can be a challenge.

FIRE CURTAINS E-CLASS Effective solution to stop the spread of fire

Class E fire curtains are used to prevent the spread of fire between buildings, floor sections and fire zones.

They are particularly suitable for securing areas that do not require personal protection, as the curtains can provide protection for up to 240 minutes, but do not have heat reduction on the opposite side.

The system is available both wall-mounted and niche-mounted and is easy to install. It requires minimal space and can be installed in locations with very low installation heights, making it suitable for locations where height can be a challenge.

SMOKE CURTAINS - Effective solution to prevent the spread of smoke

Smoke curtains D120 are used to control the spread of smoke in the event of a fire, thus creating better escape conditions in the building.

The smoke curtains consist of a technologically advanced fire- and resistance-resistant woven fabric, which is mounted in a steel box that is easily integrated into the building structure.

The curtains are tested and certified according to the EU standard EN-12101-1, which approves them to stop and control the spread of smoke and thus improve escape route safety in buildings.

The smoke curtains are prepared for external ABA/ABDL signals so that they automatically close in the event of a fire.

FIRE SHUTTER Also approved for food and pharmaceutical industries

This fire shutter is approved for 60 minutes.

The fire blind has a built-in ABDL central and can also be prepared for signal from external ABA systems. In this way, the fire blind automatically shuts down, protecting against further fire development.

The fire shutter consists of guide rails in galvanised steel and a top profile in galvanised steel.

Guide rails and Venetian blind roller can be covered with lacquered steel sheets.
